CKD Specifications
Bore Diameter (mm) φ 20, φ 25, φ 32, φ 40
Operating Mode Double Acting? Oil Resistant Type
Operating Fluid Compressed Air
Maximum Operating Pressure MPa1.0
Minimum Operating Pressure MPa0.15
Guaranteed Withstand Pressure 1.6
Ambient Temperature℃ -10～60 (but not to freeze)
Pipe Diameter mm Rc 1 / 8
Stroke Error mm/s (0～200) (over 200)
Piston Speed J50～500
Rubber Buffer Buffering
No Lubrication Required (If lubrication is necessary, please use one type of turbine oil ISO VG32)
Permissible Energy Absorption J φ 0.089 φ 0.137 φ 0.179 φ 0.278CMK2-00-20-30 CKD Short Lead Time
Nippon CKD is an air power company invested by Nippon CKD Corporation, mainly manufacturing pneumatic components such as air source treatment essentials, cylinders, solenoid valves, and other automation products.CKD mainly produces products including automation machinery (tube manufacturing, CCFL, LED manufacturing equipment, pharmaceutical blister packaging equipment, secondary battery winding machines, 3D solder paste printing board inspection machines); pneumatic control systems (FRL air source treatment components, pneumatic directional valves, cylinders, and other accessories); fluid control systems (multi-medium solenoid valves, pneumatic valves, motor valves, valves for analytical instruments, cutting fluid control special valves, high vacuum special valves, gas and natural gas LPG special valves, high purity chemical liquid valves, process gas valves) and labor-saving systems (DD-MOTOR, gap turntable).
CMK2-00-20-30
CMK2-00-20-50
CMK2-CC-20-25
CMK2-CC-20-15
CMK2-00-32-250
CMK2-00-32-100
CMK2-00-40-100
CMK2-FA-40-100
CMK2-FA-32-75-JV
CMK2-G-FA-32-75-R55-D
CMK2-FA-32-150-JV
Cylinder price CMK2-00-20-30 belongs to the Air Pressure Cylinders series under CKD company, model number CMK2-00-20-30. To purchase or inquire about Cylinder price CMK2-00-20-30, you can directly contact 158 0047 0089 (Mr. He).
1. Cylinders: Used to convert the energy of compressed air into mechanical energy to produce linear motion.
2. Pneumatic valves: Used to control the direction, speed, and pressure of airflow, regulating the operation of pneumatic systems.
3. Pneumatic motors: Devices that convert compressed air into rotary motion.
4. Air tubes and connectors: Used to connect various components in pneumatic systems and transmit air.
Yes, CKD pneumatic components require regular maintenance to ensure normal operation and extend service life. Key maintenance points include:
- Regularly check and replace seals and gaskets to prevent air leakage.
- Inspect and clean filters to ensure clean air quality.
- Lubricate moving parts to reduce wear and improve efficiency.
- Check air tubes and connectors to ensure secure and undamaged connections.
When selecting the appropriate CKD pneumatic components, consider the following factors:
Application requirements: Understand the specific working environment and tasks, such as load, speed, and stroke.
Air source conditions: Ensure that the pressure and flow of the air source meet the component’s requirements.
Installation space: Confirm available space and choose components of suitable size.
Environmental factors: Consider the temperature, humidity, and potential corrosiveness of the working environment to select suitable materials and designs.
Common pneumatic system faults include:
Air leakage: Causes efficiency decline; check seals, connections, and tubes, find leak points, and repair or replace.
Stuck cylinder piston: Possibly caused by dirt or insufficient lubrication; clean the piston and add lubricant.
Valve failure: Check electrical control signals, ensure smooth airflow, and verify if the valve itself is damaged.
Insufficient pressure: Inspect air source pressure, filters, and piping to ensure no blockage or leakage.
