CKD Cylinder LCR-16-40-T0H3-D Cylinder Switch Notes: Note 1. Only φ 50 to 100 can be manufactured. Note 2. Only the rear end anti-fall type can be manufactured. Note 3. Due to the selection of G3, the material of the sealing parts inside the cylinder is fluororubber. (T2 symbol not needed.) In addition, the combination of G2, G3 and M (corrosion-resistant type) is the same. When G2 or G3 is selected, M (corrosion-resistant type) is included. (M symbol not needed.) Note 4. The hole position for the positioning hole (E) varies with the length of the cylinder liner, please pay attention. Note 5. G4 type includes a metal scraper structure. Note 6. For the cleanroom-specific specifications P72, P73, please refer to the 'Cleanroom Component System' (Sample No.CB-033S Note: For φ40 and above with dual-color indication, preventive maintenance, and strong magnetic field resistance switches, please insert 'L1' between the product type number and the cylinder diameter and connect with a '-' (e.g.) STS-MPO-L1-50-50-T2YH3-D-F. Type of machine: Rod-type cylinder, short stroke CKD Cylinder LCR-16-40-T0H3-D Product type: Sliding bearing, stroke adjustment type, low-speed type. Cylinder diameter: φ50mm. Pipe thread type: RC thread. Stroke: 50mm. Switch model: Contact TOH switch, wire 1m. Number of switches: With 2. Options: End plate material: Steel, with positioning hole, double-acting basic type (bearing bush type) CKD Cylinder LCR-16-40-T0H3-D
Guided Cylinder LCR-16-40-T0H3-D belongs to the Air Pressure Cylinders series under CKD company, model number LCR-16-40-T0H3-D. To purchase or inquire about Guided Cylinder LCR-16-40-T0H3-D, you can directly contact 158 0047 0089 (Mr. He).
1. Cylinders: Used to convert the energy of compressed air into mechanical energy to produce linear motion.
2. Pneumatic valves: Used to control the direction, speed, and pressure of airflow, regulating the operation of pneumatic systems.
3. Pneumatic motors: Devices that convert compressed air into rotary motion.
4. Air tubes and connectors: Used to connect various components in pneumatic systems and transmit air.
Yes, CKD pneumatic components require regular maintenance to ensure normal operation and extend service life. Key maintenance points include:
- Regularly check and replace seals and gaskets to prevent air leakage.
- Inspect and clean filters to ensure clean air quality.
- Lubricate moving parts to reduce wear and improve efficiency.
- Check air tubes and connectors to ensure secure and undamaged connections.
When selecting the appropriate CKD pneumatic components, consider the following factors:
Application requirements: Understand the specific working environment and tasks, such as load, speed, and stroke.
Air source conditions: Ensure that the pressure and flow of the air source meet the component’s requirements.
Installation space: Confirm available space and choose components of suitable size.
Environmental factors: Consider the temperature, humidity, and potential corrosiveness of the working environment to select suitable materials and designs.
Common pneumatic system faults include:
Air leakage: Causes efficiency decline; check seals, connections, and tubes, find leak points, and repair or replace.
Stuck cylinder piston: Possibly caused by dirt or insufficient lubrication; clean the piston and add lubricant.
Valve failure: Check electrical control signals, ensure smooth airflow, and verify if the valve itself is damaged.
Insufficient pressure: Inspect air source pressure, filters, and piping to ensure no blockage or leakage.
