CKD Medium-sized cylinder SCA2-T-FA-80B-160

1. Cylinders: Used to convert the energy of compressed air into mechanical energy to produce linear motion.

2. Pneumatic valves: Used to control the direction, speed, and pressure of airflow, regulating the operation of pneumatic systems.

3. Pneumatic motors: Devices that convert compressed air into rotary motion.

4. Air tubes and connectors: Used to connect various components in pneumatic systems and transmit air.

Yes, CKD pneumatic components require regular maintenance to ensure normal operation and extend service life. Key maintenance points include:

- Regularly check and replace seals and gaskets to prevent air leakage.

- Inspect and clean filters to ensure clean air quality.

- Lubricate moving parts to reduce wear and improve efficiency.

- Check air tubes and connectors to ensure secure and undamaged connections.

When selecting the appropriate CKD pneumatic components, consider the following factors:

Application requirements: Understand the specific working environment and tasks, such as load, speed, and stroke.

Air source conditions: Ensure that the pressure and flow of the air source meet the component’s requirements.

Installation space: Confirm available space and choose components of suitable size.

Environmental factors: Consider the temperature, humidity, and potential corrosiveness of the working environment to select suitable materials and designs.

Common pneumatic system faults include:

Air leakage: Causes efficiency decline; check seals, connections, and tubes, find leak points, and repair or replace.

Stuck cylinder piston: Possibly caused by dirt or insufficient lubrication; clean the piston and add lubricant.

Valve failure: Check electrical control signals, ensure smooth airflow, and verify if the valve itself is damaged.

Insufficient pressure: Inspect air source pressure, filters, and piping to ensure no blockage or leakage.
