CKD solenoid valve AP11-15A-C4M-AC220V minimum operating pressure effective cross-sectional area through-hole diameter (mm) model number INO U T1: Allowable voltage fluctuation range: within ±10% of the rated voltage. 2: Leakage current should be used below the following values. When the air pressure is below 0.02M Pa, the seal is unstable, please consult before use. Voltage model number ADK11-8A~25A-L※※ZP90 10mA or less 5mA or less 40mA or less 5mA or less AC 100V 10mA or less DC 48V AC 200V DC 12V DC 100V 20mA or less DC 24V Note: The product has the following characteristics: Metal part material... The body is made of stainless steel Seal part material... Nitrile rubber (NBR) No lubrication... Oil-free specification No lubricant is used. Therefore, it can correspond to P80, P84, P94 series. When ordering, please specify the P90 series. P90 oil-free treatment Low dust generation No copper series (connecting gas part) No silicone series Use stainless steel material (connecting gas part) No halogen series (fluorine, chlorine, bromine) Construction and material restrictions Construction P9 series material restrictions Model
Two-position five-way solenoid valve AP11-15A-C4M-AC220V belongs to the Electric Actuators series under CKD company, model number AP11-15A-C4M-AC220V. To purchase or inquire about Two-position five-way solenoid valve AP11-15A-C4M-AC220V, you can directly contact 158 0047 0089 (Mr. He).
1. Cylinders: Used to convert the energy of compressed air into mechanical energy to produce linear motion.
2. Pneumatic valves: Used to control the direction, speed, and pressure of airflow, regulating the operation of pneumatic systems.
3. Pneumatic motors: Devices that convert compressed air into rotary motion.
4. Air tubes and connectors: Used to connect various components in pneumatic systems and transmit air.
Yes, CKD pneumatic components require regular maintenance to ensure normal operation and extend service life. Key maintenance points include:
- Regularly check and replace seals and gaskets to prevent air leakage.
- Inspect and clean filters to ensure clean air quality.
- Lubricate moving parts to reduce wear and improve efficiency.
- Check air tubes and connectors to ensure secure and undamaged connections.
When selecting the appropriate CKD pneumatic components, consider the following factors:
Application requirements: Understand the specific working environment and tasks, such as load, speed, and stroke.
Air source conditions: Ensure that the pressure and flow of the air source meet the component’s requirements.
Installation space: Confirm available space and choose components of suitable size.
Environmental factors: Consider the temperature, humidity, and potential corrosiveness of the working environment to select suitable materials and designs.
Common pneumatic system faults include:
Air leakage: Causes efficiency decline; check seals, connections, and tubes, find leak points, and repair or replace.
Stuck cylinder piston: Possibly caused by dirt or insufficient lubrication; clean the piston and add lubricant.
Valve failure: Check electrical control signals, ensure smooth airflow, and verify if the valve itself is damaged.
Insufficient pressure: Inspect air source pressure, filters, and piping to ensure no blockage or leakage.
